LLumar FormulaOne Window Tint Specs
Heat rejection, UV, glare and light numbers for every FormulaOne shade, taken from LLumar's published test data. Find the film and shade you want here, then send us your vehicle for a quote.
- Stratos rejects up to 65% of total solar energy
- Over 99% UV rejection on every FormulaOne shade
- Shades from 5% limo to 70% light
- Lifetime warranty on every install
Get a free window tint quote
Tell us your vehicle and the shade you like. Same business day reply, Tuesday to Saturday. Or call (858) 291-8200.
What each number means
Spec sheets use a lot of short codes. Here's what each one tells you, in plain English.
Visible light transmission
How much light gets through. Lower is darker: 5% is limo dark, 70% is light.
Total solar energy rejected
The best single number for heat. The higher it is, the cooler your cabin stays.
IR energy rejection
How much of the sun's infrared heat (780 to 2500nm) the film stops, counting heat the film absorbs and gives off.
Selective IR rejection
The share of infrared that doesn't pass straight through the glass. It's the heat you feel on your skin.
UV rejection
Blocks UV rays (300 to 380nm) that fade your interior and burn your skin. Every FormulaOne film blocks over 99%.
Glare reduction
How much less bright light reaches your eyes. Higher means less squinting into the sun.
Visible light reflection
How mirrored the glass looks from outside. Low numbers keep the factory look.
FormulaOne performance data by shade
Pick a series to see every shade. The shade number is the film's name; VLT is how much light actually gets through once it's on clear glass.
FormulaOne Stratos
Installed at our shopLLumar's top FormulaOne series. Hybrid-matrix film with no metal in it, so you get the most heat rejection with no interference with your phone, GPS or keyless entry.
| Shade | VLT | Total solar energy rejected | IR energy rejection | Selective IR rejection | UV rejection | Glare reduction | Light reflection |
|---|---|---|---|---|---|---|---|
| Stratos 05 | 7% | 65% | 65% | 94% | >99% | 93% | 5% |
| Stratos 15 | 17% | 63% | 66% | 95% | >99% | 80% | 5% |
| Stratos 30 | 32% | 59% | 66% | 96% | >99% | 63% | 6% |
| Stratos 35 | 39% | 58% | 67% | 97% | >99% | 56% | 6% |
| Stratos 40 | 42% | 57% | 67% | 97% | >99% | 52% | 6% |
| Stratos 50 | 56% | 54% | 67% | 97% | >99% | 37% | 7% |
| Stratos 70 | 69% | 49% | 66% | 96% | >99% | 21% | 8% |
FormulaOne Pinnacle
Installed at our shopNano-ceramic FormulaOne film. Strong heat rejection, a clean factory look and no signal interference, at a lower price than Stratos.
| Shade | VLT | Total solar energy rejected | IR energy rejection | Selective IR rejection | UV rejection | Glare reduction | Light reflection |
|---|---|---|---|---|---|---|---|
| Pinnacle 05 | 5% | 64% | 62% | 90% | >99% | 94% | 5% |
| Pinnacle 15 | 19% | 60% | 62% | 89% | >99% | 78% | 5% |
| Pinnacle 25 | 27% | 57% | 59% | 86% | >99% | 70% | 5% |
| Pinnacle 30 | 33% | 56% | 61% | 88% | >99% | 63% | 6% |
| Pinnacle 35 | 38% | 55% | 61% | 88% | >99% | 57% | 6% |
| Pinnacle 40 | 43% | 53% | 61% | 88% | >99% | 51% | 6% |
| Pinnacle 50 | 55% | 50% | 61% | 88% | >99% | 38% | 7% |
FormulaOne Comfort
Not installed at our shopA mid-range FormulaOne series. We don't install it. It's here so you can see how it compares with the ceramic films we use.
| Shade | VLT | Total solar energy rejected | IR energy rejection | Selective IR rejection | UV rejection | Glare reduction | Light reflection |
|---|---|---|---|---|---|---|---|
| Comfort 05 | 6% | 59% | 51% | 69% | >99% | 93% | 8% |
| Comfort 15 | 14% | 58% | 54% | 72% | >99% | 84% | 8% |
| Comfort 30 | 31% | 46% | 40% | 54% | >99% | 65% | 7% |
| Comfort 38 | 38% | 41% | 34% | 46% | >99% | 57% | 7% |
| Comfort 50 | 52% | 35% | 32% | 44% | >99% | 41% | 7% |
FormulaOne Classic
Not installed at our shopThe entry-level FormulaOne series. We don't install it. It's here so you can see how it compares with the ceramic films we use.
| Shade | VLT | Total solar energy rejected | IR energy rejection | Selective IR rejection | UV rejection | Glare reduction | Light reflection |
|---|---|---|---|---|---|---|---|
| Classic 05 | 5% | 44% | 22% | 29% | >99% | 94% | 5% |
| Classic 15 | 18% | 40% | 22% | 29% | >99% | 79% | 5% |
| Classic 30 | 33% | 36% | 22% | 29% | >99% | 63% | 6% |
| Classic 35 | 38% | 35% | 22% | 29% | >99% | 57% | 6% |
| Classic 50 | 60% | 28% | 22% | 29% | >99% | 32% | 7% |
Highlighted shade: the most heat rejection in that series.
Same darkness, very different heat
At almost the same shade, Stratos rejects 66% more solar energy than Classic. That gap is why we install only Pinnacle and Stratos.
Total solar energy rejected
Selective IR rejection
All four films let through 38 to 39% of visible light. Maroon bars are the films we install.
Picking a legal shade in California
Darker doesn't always mean cooler: nearly clear Stratos 70 rejects 49% of solar energy, more than limo-dark Classic 05 at 44%. And not every shade is legal on every window. Here's how it breaks down. Full details are in our California window tint laws guide.
Front side windows
California needs at least 70% of light to pass through the glass and film combined. Factory glass already blocks some light, so we measure yours before we recommend anything for the front windows.
Rear side and back glass
Any shade is legal as long as the car has both side mirrors. Most drivers pick 15% to 35% for privacy and heat. The 05 shades are limo dark.
Windshield
Only a clear, non-reflective strip above the AS-1 line, usually the top 4 to 5 inches. It cuts sunrise and sunset glare.
Not sure which shade?
Come see the films on glass at the shop, or tell us how dark you like it and we'll suggest a legal setup for your car.
Source: LLumar FormulaOne Window Film Performance Data (PDF), Eastman Performance Films.
Values are measured to NFRC guidelines on single-pane, nominal 1/4 inch (6mm) clear glass. They come from representative samples and can vary with manufacturing. Real results depend on your vehicle's glass. IRER counts all solar infrared heat (780 to 2500nm), including absorbed and re-radiated energy. SIRR counts solar infrared (780 to 2500nm) that doesn't pass straight through the glass. Glare reduction values are calculated and can differ slightly between similar films because of averaging and rounding.
